Pall/颇尔 Profile II RF系列滤芯
价 格
服务说明
由颇尔商城官方提供商品、发货开票及售后服务
规格型号
- R1F003
- R1F005
- R1F010
- R1F020
- R1F030
- R1F050
- R1F070
- R1F100
- R1F120
- R1F1200
- R1F150
- R1F200
- R1F300
- R1F400
- R1F700
- R1F900
- R1FYM
- R29F100
- R2F003
- R2F005
- R2F010
- R2F010SLR
- R2F010SLRBJ
- R2F020
- R2F030
- R2F030SLR
- R2F030SLRBJ
- R2F050
- R2F050SLR
- R2F070
- R2F100
- R2F1200
- R2F150
- R2F200
- R2F300
- R2F400
- R2F700
- R2F900
- R2FYM
- R3F005
- R3F010
- R3F030
- R3F050
- R3F070
- R3F100
- R3F120
- R3F1200
- R3F150
- R3F200
- R3F300
- R3F400
- R3F700
- R4F010
- R4F030
- R4F050
- R4F100
- R4F1200
- R4F200
- R1F050TIMONIUM
加入购物车
立即下单
商品介绍
商品评价(0)
Table 1
Cartridge Nominal Length
Code | Nominal | RF | RMF | MCY | AB |
1 | 10" | 254 | 254 | 245 | 258 |
| 2 | 20" | 510 | 509 | 505 | 506 |
| 298 | 30" | = | 764 | - | - |
| 3 | 30" | 768 | - | 760 | 753 |
4" | 40" | 1022 | - | 1018 | 1001 |
4 Custom-order products
Table 2
002 | 0.2μm | 030 | 3μm |
| 003 | 0.3μm | 050 | 5μm |
| 005 | 0.5μm | 070 | 7μm |
| 010 | 1μm | 100 | 10μm |
| 020 | 2μm | 200 | 20μm |
300+Coarse | 30 and +μm |
Table 3
Code | Gasket Opetions |
H13 | NBR (standard) |
| J | EPDM |
| H | Fluoroelastomer |
H4 | Silicone |
H21 | Santoprene |
Table 4
Code | 0-ring Size |
| 7 | AS568A-226 |
| 8 | AS568A-222 |
| 20 | AS568A -226 |
Table 5
Code | 0-ring Opetions |
| H4 | Silicone (standard) |
| H | Fluoroelastomer |
| J | EPDM |
